A–2
Specifications
Input Impedance: 1 MΩ//15 pF (system capacitance using
PP002) or 50 Ω ±1 %
Max. Input:
Ø 50 Ω: ±5 V DC (500 mW) or 5 V rms
Ø 1 MΩ: 250 V max (DC + peak AC ≤10 kHz)
Acquisition Modes Random Interleaved Sampling (RIS): For repetitive signals
from 1 ns/div to 10 µs/div
Single shot: For transient and repetitive signals from 50 ns/div
Sequence: Stores multiple events in segmented acquisition
memories
Deadtime Between Segments: =80 µs
Number of Segments Available:
Model Segments
9304C 9310C 9314C 2–200
9304CM 9310CM 9314CM 2–500
9310CL 9314CL 2–2000
Timebase System Timebases: Main and up to four Zoom Traces
Time/Div Range: 1 ns/div to 1000 s/div
Clock Accuracy: =±0.002%
Interpolator resolution: 10 ps
Roll Mode: Ranges 500 ms–1000 s/div
For > 50 000 points: 10–1000 s/div
External Clock: =100 MHz on EXT input with ECL, TTL or zero
crossing levels
Triggering System Modes: Normal, Auto, Single, and Stop
Sources: CH1, CH2 (plus CH3 and CH4 on four-channel
models), Line, Ext, Ext/10; Slope, Level and Coupling able to be
set independently
Slope: Positive, Negative, Window (Bislope)
Coupling: AC, DC, HF (up to 500 MHz), LFREJ, HFREJ
Pre-trigger Recording: 0–100 % of full scale adjustable in 1 %
increments
