A–3
9304C Series, 9310C Series, 9314C Series
Post-trigger Delay: 0–10 000 divisions adjustable in 0.1 div
increments
Holdoff by Time: 10 ns–20 s
Holdoff by Events: 0–99 999 999 events
Internal Trigger Range: ±5 div
EXT Trigger Max Input:
Ø 50 Ω ±1 %: ±5 V DC (500 mW) or 5 V rms
Ø 1 MΩ/15 pF: 250 V max. (DC + peak AC ≤10 kHz)
EXT Trigger Range: ±0.5 V (±5 V with Ext/10)
Trigger Timing: Trigger Date and Time listed in “Memory
Status” menu
SMART Trigger Types Signal Width: Triggers on width between two limits of between 2.5
ns and 20 s
Signal Interval: Triggers on interval between two limits of
between 10 ns and 20 s
Dropout: Triggers if the input signal drops out for a time-out
longer than 25 ns–20 s
State/Edge Qualified: Triggers on any source only if a given
state or transition — number of events, time interval — on
another source
TV: Selection of both line (up to 1500) and field number (up to
8) for PAL, SECAM, NTSC or nonstandard video
Exclusion Trigger: Triggers only on shorter-than-normal
(defined) aberrations
Autosetup AUTOSETUP button: Sets timebase, trigger and sensitivity to
display wide range of repetitive signals — amplitude 2 mV to
40 V; frequency above 50 Hz; Duty cycle greater than 0.1%
Autosetup Time: Around two seconds
Vertical Find: Automatically sets sensitivity and offset
Probes Probe Model: One PP002 probe supplied per channel; FET
probes, purchased separately, fully compatible with entire scope
series
Probe calibration: Max 1 V into 1 MΩ, 500 mV into 50 Ω,
frequency and amplitude programmable, pulse or square wave
able to be selected, rise and fall time 1 ns typical (calibrator also
offers trigger or Pass/Fail output)
