A–4
Specifications
Signal Viewing
Display CRT: 12.5 x 17.5 cm (9” diagonal)
raster
Resolution: 810 x 696 points
Grids: 1, 2, or 4 grids.
Formats: YT, XY and both together
Graticules: Internally generated; separate
intensity control for grids and waveforms
Waveform Style: Vectors, which can be switched on and off,
connect individual sample points highlighted as dots
Modes: Normal, XY, Variable or Infinite Persistence
Real-time Clock: Date, hours, minutes, seconds
Vertical Zoom: Up to 5x Vertical Expansion (50x with averaging,
up to 40 µV sensitivity)
Horizontal Zoom:
Model Zoom Factor
9304C 9310C 9314C 1000x
9304CM 9310CM 9314CM 5000x
9310CL 9314CL 20 000x
Signal Analysis
Waveform Processing Processing Functions: Add,
Subtract, Multiply, Divide, Negate,
Identity and Summation Averaging;
four functions performable at one
time
Average: Summed averaging of up to
1000 waveforms in the basic instrument;
up to 10
6
averages possible with optional
WP01 Advanced Waveform Math Package
