A–1
Appendix A: Specifications
A
Ø 9304C Series, 9310C Series, 9314C Series
Signal Capture
Acquisition System Bandwidth (-3 dB):
Ø 9304C Series
Ø @ 50 Ω: DC to 200 MHz
Ø @ 1 MΩ: DC to 160 MHz
typical at probe tip
Ø 9310C/9314C Series ):
Ø @ 50 Ω: DC to 400 MHz
Ø @ 1 MΩ: DC to 230 MHz typical at probe tip
Number of Channels:
Ø 9304C/9314C Series: four
Ø 9310C Series: two
Number of Digitizers:
Ø 9304C/9314C Series: four
Ø 9310C Series: two
Max. Sample Rate: 100 MS/s simultaneously on each channel
Sensitivity: 2 mV/div to 5 V/div, fully variable
Scale Factors: Wide range of probe attenuation factors
Offset Range:
Ø 2.00–9.9 mV/div: ±120 mV
Ø 10.0–199 mV/div: ±1.2 V
Ø 0.2–5.0 V/div: ±24 V
DC Accuracy: ±2 % full scale (eight divisions) at 0 V offset
Vertical Resolution: 8 bits
Bandwidth Limiter: 30 MHz
Model 9304C 9304CM 9310C 9310CM 9310CL 9314C 9314CM 9314CL
Number of
Channels
Four Two Four
Acquisition
Memory per
Channel
50 k 200 k 50 k 200 k 1 M 50 k 200 k 1 M
Input Coupling: AC, DC, GND
Note: Where a
particular model or a
series is NOT
mentioned, the
specification
concerned applies to
all related models.
