8–3
Edge Trigger
Selecting Edge and its menus (Fig. 8–2) causes the scope
to trigger whenever the selected signal source meets the
trigger conditions. The trigger source is defined by the
trigger level, coupling, slope or hold-off.
Figure 8–2. Edge Trigger Menu (see page 8–9).
Edge
Trigger on
Coupling
Slope Pos|Neg|Window
DC|AC|LFREJ|HFREJ|HF
1|2|3|4|Ext|Ext10|Line
Holdoff
Off|Time (10 ns to 20 s)
|Events (1to 99 999 999)
To Next Page
