12–8
UTILITIES
File-naming Conventions As in MS-DOS, the file name can take up to eight characters
followed by an extension of three characters.
A file is treated as:
Ø Panel setup if its extension is PNL
Ø Waveform if its extension is a three-digit number
Ø Waveform template if its extension is TPL
Ø Hardcopy if its extension is TIF, BMP, or PRT.
The instrument has a pre-defined naming convention for the
eight-character file names and directory names, and these default
names can be customized, as shown in this table.
If the new file being stored bears the same name as an existing file
on the same storage medium, the old file will be deleted.
Type Default Name Customized Name
Manually stored waveform files Stt.nnn xxxxxxxx.nnn
Automatically stored waveform
files
Att.nnn xxxxxxxx.nnn
Panel files Pnnn.PNL xxxxxnnn.PNL
Hard copy files
Dnnn.TIF
Dnnn.PRT
xxxxxnnn.TIF
xxxxxnnn.PRT
Template files LECROYvv.TPL Cannot be changed
Directory name LECROY_1.DIR xxxxxxxx
Spreadsheet Sttnnn.TXT xxxxxnnn.TXT
Matlab Sttnnn.DAT xxxxxnnn.DAT
Mathcad Sttnnn.PRN xxxxxnnn.PRN
KEY
x any legal DOS file-name character w
the template version number: for example, for a
version 2.2, the template is saved as
LECROY22.TPL
tt
the trace name of C1, C2, C3, C4, TA, TB, TC,
TD
TIF
BMP
hardcopy graphics image files
nnn
a 3-digit decimal sequence number starting at
001 that is automatically assigned
PRT hardcopy printer files.
