A–6
Specifications
ERES: Low-Pass digital filter provides up to 11 bits vertical
resolution; sampled data always available, even when trace turned
off; any of above modes usable without destroying data — with
WP01 Option
FFT: Spectral Analysis with five windowing functions and FFT
averaging, with optional WP02 Spectrum Analysis Package
Histogramming and Trending: With optional WP03 Parameter
Analysis Package, in-depth diagnostics on waveform parameters
Internal Memory Waveform Memory: Up to four 16-bit Memories (M1, M2, M3, M4)
Processing Memory: Up to four 16-bit Waveform Processing
Memories (A, B, C, D)
Setup Memory: Four non-volatile memories; optional cards for
high-capacity waveform and setup storage
Cursor Measurements Relative Time: Arrow cursors measure time and voltage
differences relative to each other
Relative Voltage: Horizontal bars measure voltage differences up
to ±0.2% full-scale in single-grid mode
Absolute Time: Cross-hair marker measures time relative to trigger
and voltage with respect to ground
Absolute Voltage: Reference bar measures voltage with respect to
ground
Interfacing Remote Control: By GPIB and RS-232-C for
all front-panel controls, internal functions
RS-232-C Port: Asynchronous up to 115.2 Kb/s
for computer or terminal control, or printer or
plotter connection
GPIB Port: (IEEE-488.1) Configurable as
talker/listener for computer control and fast
data transfer; command language compliant
with IEEE-488.2
Centronics Port: Hardcopy interface
PC Card (PCMCIA II/III Ports): Optional for memory cards, flash
cards and removable hard disks
Floppy Disk: High density 3.5-inch floppy disk drive (DOS format)
Hardcopy: TIFF and BMP formats
available for import to Desktop
Publishing programs; printers and
plotters — HP DeskJet, HP ThinkJet,
