A–14
Specifications
Autosetup AUTOSETUP button: Sets timebase, trigger and sensitivity to
display wide range of repetitive signals — amplitude 2 mV to
40 V; frequency above 50 Hz; duty cycle greater than 0.1%
Autosetup Time: Around two seconds
Vertical Find: Automatically sets sensitivity and offset
Probes Probe Model: One PP002 probe supplied per channel, DC to
250 MHz typical at probe tip, 600 V max.; FET probes,
purchased separately, fully compatible with entire scope series
Probe calibration: Max 1 V into 1 MΩ, 500 mV into 50 Ω,
frequency and amplitude programmable, pulse or square wave
able to be selected, rise and fall time 1 ns typical (calibrator also
offers trigger or Pass/Fail output)
Signal Viewing
Display CRT: 12.5 x 17.5 cm (9” diagonal)
raster
Resolution: 810 x 696 points
Grids: 1, 2, or 4 grids.
Formats: YT, XY and both together
Graticules: Internally generated;
separate intensity control for grids and
waveforms
Waveform Style: Vectors, which can be switched on and off,
connect individual sample points highlighted as dots
Modes: Normal, XY, Variable or Infinite Persistence
Real-time Clock: Date, hours, minutes, seconds
Vertical Zoom: Up to 5x Vertical Expansion (50x with averaging,
up to 40 µV sensitivity, with optional WP01 Advanced Waveform
Math Package)
Horizontal Zoom: Waveforms can be expanded to give 2–2.5
points/div
Model Zoom Factor
9344C 9350C 9354C 2000x
9344CM 9350CM 9354CM 10 000x
