A–16
Specifications
Signal Analysis
Waveform Processing Processing functions: Add, Subtract,
Multiply, Divide, Negate, Identity,
Summation Averaging, and Sine x/x;
four functions performable at one
time Average: Summed averaging
of up to 1000 waveforms in the basic
instrument; up to 10
6
averages possible
with optional WP01 Advanced Waveform
Math Package
Extrema: Roof, Floor or Envelope values of from 1 to 10
6
waveforms with optional WP01 Advanced Waveform Math
Package
ERES: Low-Pass digital filter provides up to 11 bits vertical
resolution; sampled data always available, even when trace turned
off; any of above modes usable without destroying data — with
WP01 Option
FFT: Spectral Analysis with five windowing functions and FFT
averaging, with optional WP02 Spectrum Analysis Package
Histogramming and Trending: With optional WP03 Parameter
Analysis Package, in-depth diagnostics on waveform parameters
Internal Memory Waveform Memory: Up to four 16-bit Memories (M1, M2, M3, M4)
Processing Memory: Up to four 16-bit Waveform Processing
Memories (A, B, C, D)
Setup Memory: Four non-volatile memories; optional cards or
disks for high-capacity waveform and setup storage
Cursor Measurements Relative Time: Arrow cursors measure time and voltage
differences relative to each other
Relative Voltage: Horizontal bars measure voltage differences up
to ±0.2% full-scale in single-grid mode
Absolute Time: Cross-hair marker measures time relative to trigger
and voltage with respect to ground
Absolute Voltage: Reference bar measures voltage with respect to
ground
