9384C Series
Ø 9384C Series
Signal Capture
Acquisition System Bandwidth (-3 dB):
Ø @ 50 Ω: DC to 1 GHz
10 mV/div and above
Ø @ 1 MΩ: DC to 500 MHz typical
at PP005 probe tip
Ø 1 GHz FET probe optional
Number of Channels: four
Number of Digitizers: four
Sensitivity:
Ø 50 Ω: 2 mV/div to 1 V/div, fully variable
Ø 1 MΩ: 2 mV/div to 10 V/div, fully variable
Scale Factors: Wide range of probe attenuation factors
Offset Range:
Ø 2.00–4.99 mV/div: ±400 mV
Ø 5–99 mV/div: ±1 V
Ø 0.1–1 V/div: ±10 V
Ø 1–10 V/div: ±100 V (1 MΩ Only)
Ø ±20 V over the full sensitivity range using AP 020 FET
probe
9384C Series
MEMORY PER CHANNEL (IN POINTS)
Model
CHANNELS USED
(PEAK DETECT ON/OFF)
MAX SAMPLE RATE
C CM/CTM CL
ACTIVE CHANNELS
All (Peak Detect OFF) 1 GS/s 100k 500k 2M All
100 MS/s data 50k data
250k
data
1M data All
All (Peak Detect ON)
400 MS/s peak 50k peak
250k
peak
1M peaks 2.5 ns peak detect
Two Channels Paired
(Peak Detect OFF)
2 GS/s 200k 1M 2M CH 2 + CH 3
