LeCroy 9300C Series

E–1
Appendix E: ASCII Waveform
Export
E
Using ASCII-Stored Files
The ASCII waveform storage feature allows waveforms to
be stored to a mass-memory device in any of three ASCII
formats: Spreadsheet, Mathcad and MATLAB. Each format
is tailored for a commonly used analysis package. The
user-interface changes supporting ASCII waveform storage
are found in the STORE menu (see Chapter 13).
The table below summarizes the three formats’ basic layout.
Examples of the use of each format are given on the following
pages.
Format Header
Format
includes some
form of header
before the
data
Time
Values
Format stores
time values
with each
amplitude
value
Amplitude
Values
Format stores
amplitude
values
Sequence
Times
Header
contains
sequence time
information for
each sequence
segment
Multi-
Segment
Format
concatenates
multiple
segments of a
sequence
waveform
Dual Array
Format allows
dual-array
data (i.e.
Extrema, or
complex FFT)
to be stored
Spreadshee
t
Yes Yes Yes Yes Yes Yes
Mathcad Yes Yes Yes Yes Yes Yes
MATLAB No No Yes No Yes No
Note: Once stored in ASCII, waveforms cannot be
recalled into the DSO.
