LeCroy 9300C Series

E–12
Appendix E
Multi-Segment Example
LECROY9354,935412345
Segments,3,SegmentSize,502
Segment,Trig Time,TimeSinceFirstSegment
#1,21 Mar 1990 9:37:08,0.0
#2,21 Mar 1990 9:37:13,5.0
#3,21 Mar 1990 9:37:15,7.0
Time,Ampl
0.0,1
0.1,2
...
0.0,1.1
0.0,2.1
...
0.0,1.05
0.0,2.05
Dual-Array Example
LECROY9354,935412345
Segments,1,SegmentSize,502
Segment,Trig Time,TimeSinceFirstSegment
#1,21 Mar 1990 9:37:08,0.0
Time,Ampl
0.0,1.1,1.1
0.1,2.1,2.1
...
Note:
Ø The basic structure of the Spreadsheet format is a
header containing scope identification information,
followed by a block containing trigger times for multi-
segment waveforms, followed by the data itself.
Ø This format is compatible with the ASCII import of the
LeCroy LW4xx Arbitrary Function Generator.
