E–14
Appendix E
Multi-Segment Example
“LECROY9354,935412345”
“23-March-90,12:44:23”
3 502
Segment TimeSinceFirstSegment
1 0.0
2 5.0
3 7.0
Time Ampl
0.0 1
0.1 2
.....
0.0 1.1
0.1 2.1
.....
0.0 1.05
0.1 2.05
Note:
Ø The format created for MathCad is very similar to the
Spreadsheet format, but with some differences due to the
way MathCad interprets the header information.
Ø One of the most important of these is that the absolute
trigger time is only given for the first segment, with relative
times (in units of seconds) being included for each segment.
Ø Another difference is that the scope identification and
trigger time are wrapped in quotes to ensure that MathCad
does not attempt to import them.
