Contents
Chapter 8 — Triggers and When to Use Them
Choosing the Right Trigger .......................................................8–1
Edge or SMART?..............................................................................8–2
Edge Trigger......................................................................................8–3
TRIGGER SETUP: Edge................................................................8–9
SMART Triggers.............................................................................8–10
TRIGGER SETUP: SMART ........................................................ 8–29
Chapter 9 — ZOOM + MATH
Zoom and Math Controls............................................................. .9–1
Chapter 10 — Zoom, Mathematics and Math Setup
Zooming for Precise Waveform Measurements...........10–1
Math Functions and Options ..............................................10–2
Using Waveform Mathematics...........................................10–5
Configuring for Zoom and Math.........................................10–6
Setting Up FFT Span and Resolution .............................10–17
Chapter 11 — Display
Setting Up the Display........................................................ 11–1
Chapter 12 — UTILITIES
Printing, Storing, Using Special Modes ........................... 12–1
Hardcopy Setup............................................................................ 12–2
Time/Date Setup........................................................................... 12–4
GPIB/RS232 Setup....................................................................... 12–5
Mass Storage Utilities .............................................................. 12–7
Special Modes........................................................................ 12–19
CAL BNC Setup............................................................................. 12–21
