LeCroy 9300C Series

8–19
Applications Pattern Trigger is useful in digital design for the testing of complex
logic inputs or data transmission buses.
Figure 8–15. Pattern Trigger: Trigger when pattern conditions met.
CH 1
Generated Trigger (Pattern Entering)
Pattern 1H*2L
Threshold
CH 2
Generated Trigger (Pattern Exiting)
Threshold
High
High
Low
Low
