10–5
Whenever the selected maximum number of sweeps is reached,
the accumulation stops. The same process may be interrupted
by changing the trigger mode from Normal to Stopped or by
turning off the function trace. Accumulation will continue when
these actions are reversed.
The currently accumulated extrema waveform may be reset by
either pushing the CLEAR SWEEPS button or by changing an
acquisition parameter such as input gain, offset, coupling, trigger
condition, or the timebase- or bandwidth-limit. The number of
currently accumulated waveforms is displayed in the function’s
Displayed Trace Label of that of its zoom expansion.
Whenever the maximum number of sweeps is reached, an even
larger number can be accumulated simply by changing the
number in the “SETUP” “for” menu. However, the other
parameters must be left unchanged or the extrema calculation
will be restarted.
