LeeBoy L150 - L500 Skid Mount Specifications

TACK DISTRIBUTOR
11
TACK DISTRIBUTOR
LeeBoy Model L250 Track Distributor
(Skid Mount Specifications)
Engine: 5 HP Honda gas engine
Asphalt Pump: Specially designed .308 CI Pump
Heat System: Two (2) 54,000 BTU Propane
burners, one (1) starter burner
and a 30 lb. fuel tank
Temperature
Gaug
e:
0-300 deg
rees Fahrenheit
Tank
Dimensions: Length: 48 1/2"
Width: 42 1/2"
Height: 32 1/2"
Flush Tank: Seven (7) gallon
Hose & Reel: 1/2" x 40' heavy duty hose with a
heavy duty re-coil reel
Wand: Six (6) foot wand with on/off valve
and remo
vable spray tip
Fill Spout: 10" x 10"
Clean Out: 4"
Access Valve: 1”
Dimensions: Length: 62"
Width: 48"
Height:
80 5/8"
Shipping Weight: 1,260 lbs.
Loaded Weight: 3,250 lbs.
Optional
Equipment: Eight (8) foot spray bar that
folds to a lockable position.
Separate cut-off valves to
control each spr
ay nozzle.
5 HP Briggs & Stratton
62"
78 13/16"
7 13/16"
48"
80 5/8"
