LeeBoy L150 - Selector Valve Assembly; Spray Select Valve Assembly, Trailer; Spray Select Valve Assembly, Skid

TACK DISTRIBUTOR
32
TACK DISTRIBUTOR
Selector Valve Assembly
4
5
4
2
1
3
4
2
1
2
3
5
5
6
4
2
3
1
3
2
1
3
4
5
5
4
1
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 910080 VALVE, SELECTOR
2 2 280270 NIPPLE, 1/2" PIPE x CLOSE
3 1 280290 BALL VALVE, 1/2"
4 3 2404-8-8 ADAPTER, PIPE TO HOSE
5 2 280140 TEE, 1/2" PIPE
Spray Select Valve Assembly, Trailer
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 280330 ELBOW, STREET 1/2" NPT
2 2 280290 BALL VALVE, 1/2"
3 2 2404-8-8 ADAPTER, PIPE TO HOSE
4 1 280090 NIPPLE, 1/2" x 5 1/2" LG
5 2 280270 NIPPLE, 1/2" PIPE x CLOSE
6 1 280140 TEE, 1/2" PIPE
Spray Select Valve Assembly, Skid
ITEM NO. QTY. PART NO. DESCRIPTION
1 3 280270 NIPPLE, 1/2" PIPE x CLOSE
2 1 280140 TEE, 1/2" PIPE
3 2 280330 ELBOW, STREET 1/2" NPT
4 2 280290 BALL VALVE, 1/2"
5 2 2404-8-8 ADAPTER, PIPE TO HOSE
