TACK DISTRIBUTOR
13
TACK DISTRIBUTOR
LeeBoy Model L250 Track Distributor
(Skid Mount Specifications)
Engine: 5 HP Honda gas engine
Asphalt Pump: Specially designed .308 CI Pump
Heat System: Two (2) 54,000 BTU Propane
burners, one (1) starter burner
and a 30 lb. fuel tank
T
emperature
Gauge: 0-300 degrees Fahrenheit
Tank
Dimensions: Length: 83 7/8"
Width: 48 1/2"
Height: 32"
Flush
Tank:
Se
ven (7) gallon
Hose & Reel: 1/2" x 40' heavy duty hose with a
heavy duty re-coil reel
Wand: Six (6) foot wand with on/off valve
and removable spray tip
Fill Spout: 10" x 10"
Clean Out: 4"
Access Valve:
1”
Dimensions: Length: 103"
Width:
48 1/2"
Height: 64 5/8"
Shipping Weight: 2,700 lbs.
Loaded Weight: 6,700 lbs.
Optional
Equipment: Eight (8) foot spray bar that
folds to a lockable position.
Separ
ate cut-off valves to
control each spray nozzle.
5 HP Briggs & Stratton
5 7/8"
48 1/2"
5 1/8"
64 5/8"
112 3/8"
103"
