3) Use a screwdriver with a 2.5 mm wide sha to ghten the screws above each terminaon point to
secure the wires, using a torque of 0.196 N·m (2 kgf·cm).
▶
To make connecons aer the terminal module is separated:
You can also connect a detector/switch when the terminal module is separated from the sensor box.
1) Loosen the screws at two sides of the terminal module.
Note: The two screws are not removable so just loosen them.
23
