Doc No. FM0814 issue 5 Page 12
10. DECT HANDSET MULTI CHARGER & PSU
The optional Multi Charger is a modular system, each Multi Charger module can charge up to 5 Spectralink
7202/7212 DECT handsets at the same time. Using the included link cable, up to 3 Multi Charger modules
can be connected together horizontally or vertically to provide charging from one PSU, eliminating the need
for 15 separate mains sockets, PSU’s, and chargers.
The Multi Charger can be desk mounted or fixed to the wall. It is possible to wall mount an unlimited
number of Multi Chargers simultaneously and it is possible to expand the numbers should your needs grow.
With the Multi Charger you can benefit from access to fully charged handsets at any time, it is easy to see
which handsets are charged and if any are missing.
Multi Charger Blocks and PSU’s are ordered separately, remember; 1 PSU module can power up to 3
Charger Blocks (15 handsets).
PART NUMBERS
Refer to the Spectralink Handset Multi Charger installation guide (see section 6)
Power Supply for up to
3 Charger Blocks
Desk or wall mount
Multi Charger Block
for up to 5 Handsets
358mm x 63mm x 63mm
(HxWxD)
Link Cable for connecting
up to 3 Charger Blocks
Spectralink Ref.
Tynetec Part No.
Product
0250 9400
W03034
Spectralink Multi Charger (Inc. Link Cable)
0250 9501
W03043
Spectralink Multi Charger UK PSU
