LEGRAND Tynetec Advent XT2 Installation Manual

Doc No. FM0814 issue 5 Page 48
34. SPECIFICATION: UNINTERRUPTIBLE POWER SUPPLY
UPS
Manufacturer/Model No.
APC BE850G2-UK
Aidcall Part No.
ZXT548
EMC Approvals
EN 62040-2:2006+AC:2006 (IEC 62040-2:2005) Category C1
Safety Approvals
UL 1778
Input
Nominal Input Voltage
230V AC
Input Frequency Range
47-63Hz
Max Input Current
6.0A
Efficiency at Full load
80%
Input Connection
1.8 metres long with BS 1363A moulded non-rewireable 13A UK Plug
Fuse Type/Rating
BS 1362 1” 240V AC 10A
Output
Output Capacity (6 Outlets)
850VA 520 Watts (1 hour 30 minutes @ 40W typical)
Output Voltage (on utility)
230V AC 47-63Hz
Output Voltage (on battery)
230V AC +/- 8% 50Hz +/- 1Hz
Output Connections
8 x BS 1363 Sockets (6 with battery back-up plus surge protection and
2 with surge protection only)
Standby Battery
Battery Type
Maintenance-free, sealed lead acid battery, leak proof
Battery Life
2-5 Years (depending on number of discharge cycles and temperature)
Battery Recharge Time
16 Hours (typical)
Replacement Battery Kit
APC RBC17
Features
Status LED’s
Power, on battery, replace battery and overload
Audible Alarm
Beep when on battery, rapid beep for low battery, constant for
overload
Mute Button
Yes (to silence audible alarms)
USB Ports
2.4A (1 x Type A and 1 x Type C)
Mechanical
Enclosure
Black, free standing or wall mount, indoor use only
Ingress Protection Rating
IP20
Dimensions
120mm x 130mm x 365mm (HxWxD)
Weight
4.5kg
Environment
Operating Temperature Range
0
o
C to 40
o
C
Operating Humidity
0-90% RH, Non-condensing
