33. SPECIFICATION: REPEATER BATTERY BACKED PSU
Power Supply
Manufacturer/Model
Elmdene G13802N-A
Tynetec Part No.
W00525
Compliance
EMC Approval
2014/30/EU
LVD Approval
2014/35/EU
Environmental Approval
RoHS2: 2011/65/EC, WEEE: 2012/19/EU
Electrical
Input Voltage
100V to 240V AC 50/60Hz
Output Voltage/Current
13.8V DC @ 2A
Output Ripple
150mV peak to peak
Mains Fuse Protection
T2.0A 20mm HRC
Load Fuse Protection
F2.0A 20mm Glass
Features
PSU Type
Switch Mode with Electronic Overload Protection
LED Indicators
Green = Mains Present and Red = Fault (Output/Battery Fuse Fail)
Battery Protection
Re-settable PTC
Mechanical
Colour
White
Material
Powder coated 18 SWG steel
Enclosure
Wall mounting with hinged lid
Dimensions
200mm x 230mm x 80mm (HxWxD)
Weight
1.85 kilograms (excluding battery)
Ingress Protection Rating
IP41 (indoor sheltered)
Environmental
Operating Temperature Range
-10
o
C to +40
o
C
Operating Humidity
75% RH, Non-condensing
Standby Battery
Manufacturer/Model
Yuasa NP3.4-12
Tynetec Part No.
F00040
Type
12V 3.4Ah Rechargeable Lead Acid
Dimensions
133mm x 66mm x 60mm (LxWxH)
Weight
1000 grams
Operating Temperature Range
-15
o
C to 50
o
C
