Doc No. FM0814 issue 5 Page 13
11. IP-DECT SERVER 200 SINGLE CELL
The IP-DECT Server 200 Single Cell (with built-in Base Station) option is easy to deploy for a small scheme
with up to 6 Repeaters and 12 DECT handsets. Where there is the need for more users or coverage of a
larger area, then the IP-DECT Server 400 Multi Cell solution may be used.
LED INDICATOR
The front cover Status LED will indicate the IP-DECT Server/Base Station status by different colours and
flash patterns, see the table below;
Busy (all channels in use)
Reset/shut-down in progress
Steady Red for 5 Seconds
then Fast Red Flashing
Reset to factory settings
RESET BUTTON
You can restart the IP-DECT Server/Base Station by pressing the RESET button on the bottom face, see the
table below for the 2 possible actions;
Server/Base Station restarts when the button is released
Long press (5-9 Secs) until front LED
flashes red then release button
Reset to factory defaults (original IP setting and empty user
data base) and restart.
Refer to the Spectralink IP-DECT Server 200/400/6500 installation guide (see section 6)
Surface Mount ABS Enclosure
100 x 100 x 43mm (HxWxD)
8V PSU Port (if PoE not used)
Ethernet Port (PoE)
Green Flashing LED = Activity
Yellow LED = Ethernet OK
IP-DECT Server 200 Single Cell
