LEGRAND Tynetec Advent XT2 Installation Manual

Doc No. FM0814 issue 5 Page 39
25. SPECIFICATION: HANDSET MULTI CHARGER & PSU
Multi Charger Block
Manufacturer/Model No.
Spectralink 0250 9400
Tynetec Part No.
W03034
No. of Handsets per Block
5 max
No. of Blocks per PSU
3 max (15 handsets)
Link Cable
200mm long, fitted with 2 moulded 2.1mm Barrel Plugs (5.5mm OD)
Mechanical
Enclosure
White, desktop or wall mount, indoor use only
Dimensions
358mm x 63mm x 63mm (HxWxD)
Weight
450 grams
Multi Charger Power Supply
Manufacturer/Model No.
Spectralink 0250 9501 (FranMar FRA032-S07-4)
Tynetec Part No.
W03043
Compliance
Safety Approvals
IEC/UL/EN 60950-1
EMC Approvals
EN55022, EN6100-3-2, EN61000-4-2, EN55024
Electrical
Input Voltage/Current
100-240VAC 47-63Hz 1.0A
Output Voltage/Current
6V DC 5A
Efficiency
CEC Level V
Standby Power
<0.075 Watts
Max Power
32 Watts
Output Lead
1 metre long black AWM 1185 16 AWG
Output Connector
Moulded 2.1mm Barrel Plug Centre Positive (5.5mm OD)
Mains Lead
1.5 metres long black 227 IEC 53 (RVV) 3 core 0.75
2
mm
Mains Connectors
BS 1363 moulded 13A UK Plug & moulded IEC C13 Female Plug
Fuse Type/Rating
BS 1362 1” 240V AC 10A
Features
LED Indicator
Green: Supply Healthy
Solid State Protection
Electronic OVP, OLP & Short Circuit Protection
Mechanical
Colour
Black
Enclosure
Desktop design, indoor use only
Dimensions
117mm x 53mm x 31mm (LxWxD)
Weight
250 grams (exc. Mains Lead)
Environmental
Operating Temperature Range
0
o
C to +40
o
C
Operating Humidity
20-90% RH, Non-condensing
