CS10/CS15 & GS Sensors, Technical Data 111
Weight
Power
Electrical data
Type Weight [kg]/[lbs]
GS05 with CS10 0.750/1.653
GS06 with CS15 0.910/2.006
Power consumption: 0.5 W typically, 45 mA
External supply voltage: Nominal 12 V DC ( ), voltage range 5 V-28 V DC
Type GS05/GS06
Voltage -
Current -
Frequency GPS L1 1575.42 MHz
GLONASS L1 1602.5625 MHz-1611.5 MHz
Gain Typically 27 dBi
Noise Figure Typically < 2 dBi
