CS10/CS15 & GS Sensors, Operation
3.1.2 Fixing a Hand Strap to the CS
Fixing the CS to a
hand strap step-
by-step
Step Description

Turn the CS field controller over.
1. Take the end of the hand strap and clip it to the base of CS field controller.
2. Compress the clips of the main hook.
3. Lower the main hook onto the pivot knob of the CS field controller. A click
can be felt when the clip is secure.
CS_009
1
2
4
3
