Leica CS15 - Operation; Equipment Setup

36
CS10/CS15 & GS Sensors, Operation
3 Operation
3.1 Equipment Setup
3.1.1 Fixing the Display Foil to the CS
Fixing the display
foil to the CS step-
by-step
Step Description

Ensure that the display of the CS is free of dust and grease.

The non-reflecting display foil has a silver-coloured sticker to peel away
the carrier foil from the actual display foil.
1. Touch the silver-coloured sticker with two fingers and pull it slowly
upwards. The carrier foil is peeling away.

Do not peel the carrier foil more than 2 cm - 3 cm away.
CS_029
1
2
3
4
