CS10/CS15 & GS Sensors, Operation 75
3.8 Using the Digital Camera
Overview Both CS field controllers are equipped with a digital camera located at the underside
(refer to "1.4 CS Components"). If a hand strap or pole holder plate is mounted, the
camera view is not limited. The camera application can be started from the desktop
icon Camera or from the Start menu Start - Programs - Camera.
Taking a picture
step-by-step
Step Description
1. Aim the camera to the desired target.
2. Check the view at the display.
3. Press OK or click Capture to take the picture.
Capture changes to Save.
4. Press OK again or click Save to open the Save As dialog.
5. Click Discard to reject the picture.
