CS10/CS15 & GS Sensors, Technical Data
6.5 Antennas Technical Data
Description and
use
The table gives a description and the intended use of the antenna.
Dimensions
Connector
Mounting
Weight
Type Description Use
AS05 L1 GPS, GLONASS SmartTrack+
antenna with built-in ground
plane.
With CS10/GS05, CS15/GS06.
Type AS05
Height 6.2 cm
Diameter 17.0 cm
AS05: TNC female
AS05: 5/8" Whitworth
AS05: 0.4 kg
