CS10/CS15 & GS Sensors, Technical Data
6.2.3 Technical Data
Description and
use
The table gives a description and the intended use of the GS05/GS06.
Dimensions
Connector 5 pin interface port
Type Description Use
GS05 L1 GPS, GLONASS SmartTrack+
antenna.
With CS10 field controller.
GS06 L1 GPS, GLONASS SmartTrack+
antenna.
With CS15 field controller.
Type Length [m] Width [m] Thickness [m]
GS05 with
CS10
0.278 0.102 0.045
GS06 with
CS15
0.323 0.125 0.045
