CS10/CS15 & GS Sensors, Operation
3.7 LED Indicators on GS08plus/GS12
LED indicators Description
The GS08plus/GS12 instrument has Light Emitting Diode indicators. They indicate the
basic instrument status.
Diagram
a) Tracking LED (TRK)
b) Bluetooth LED (BT)
c) Power LED (PWR)
TRK
BT
PWR
ON
OFF
003983_001
abc abc
