70
CS10/CS15 & GS Sensors, Operation
3.6 LED Indicators on CTR16
LED indicators Description
The CTR16 has a Light Emitting Diode indicator. It indicates the basic radio status.
Diagram
a) TPS radio LED
CS_033
a
