120
CS10/CS15 & GS Sensors, Technical Data
6.4.3 Technical Data
Description and
use
The table gives a description and the intended use of the GS08plus/GS12.
Dimensions
Connector • 8 pin LEMO-1
• 5 pin SmartStation clip-on-contacts (GS12 only)
Mounting 5/8" Whitworth
Type Description Use
GS08plus L1, L2 GPS, GLONASS SmartTrack+
antenna.
With CS10 field controller.
GS12 L1, L2, L5 GPS, GLONASS, Galileo Smart-
Track+ antenna.
With CS10 or CS15 field
controller.
Type Height Diameter
GS08plus 0.071 m 0.186 m
GS12 0.089 m 0.186 m
