CS10/CS15 & GS Sensors, Safety Directions
Air terminal
arrangement, plan
view
Grounding the
instru-
ment/antenna
a) Antenna
b) Support structure
c) Air terminal
GS_039
a
b
c
a) Antenna
b) Lightning conductor array
c) Antenna/instrument connection
d) Metallic mast
e) Connection to earth
GS_040
e
d
c
a
b
