Designation of Parts
View from right (illustration without door)
34 Memory card slots
View from left (illustration without cover)
35 Threaded flash sync socket
36 Remote control / Headphone / external microphone socket
37 HDMI socket
38 USB socket
Bottom views
39 Battery
40 Battery release lever
41 Cover over handgrip contacts
42 Hole for multi-function hand gripguide pin
43 Tripod plate with
1
⁄4" thread
44 Hole for rotation prevention pin
45 Contacts in battery compartment (battery removed)
46 Contacts for handgrip (cover removed)
