8 TPS1200+/TS30/TM30 Application Programs - Getting
Started
Description of fields for Determine Coordinate System
<Job:> Choicelist • The active job.
• For Stakeout and Reference Line:
points which are occupied after
staking out are stored in this job.
<Coord System:> Output • The coordinate system currently
attached to the selected <Job:>.
<Codelist:> Choicelist • No codes are stored in the selected
<Job:>. All codelists from Main
Menu: Manage...\Codelists can be
selected.
Output • Codes have already been stored in
the selected <Job.>.
<DTM Job:> Choicelist • Available for Stakeout if <Use DTM:
DTM only> and <Use DTM: DTM &
Stake Job> in STAKEOUT Configu-
ration, Heights page.
• Available for Reference Line if
<Heights: Use DTM Model> in
REFLINE Configuration, Heights
page.
• To select a DTM to be staked and to
select the active DTM layer to be
used. Heights are then staked out
relative to the selected DTM.
<Config Set:> Choicelist • The active configuration set.
<Reflector:> Choicelist • The active reflector.
<Add. Constant:> Output • The additive constant stored with the
chosen reflector.
Field Option Description
<Name:> User input A unique name for the coordinate system.
The name may be up to 16 characters in
length and may include spaces. Input is
mandatory.
)
Entering the name of an
existing coordinate system will
allow that system to be
updated.
<WGS84Pts Job:> Choicelist The job from which the points with
WGS84 coordinates will be taken.
<Local Pts Job:> Choicelist The job from which the points with local
coordinates will be taken.
Field Option Description
