LELY DISCOVERY - Page 38

Description of components
Chapter 3 - page 6
3
D-H002.0607EN
Table 3.5 Connector 1201 - Gyroscope
Pin Description Colour Voltage (DC)
1 Black 0.0
2 Green 2.5
3Grey5
4 Not used
Table 3.6 Connector 1202 - Gyroscope
Pin Description Colour Voltage (DC)
1White0.0
2 Yellow 2.5
3 Not used
4 Not used
Table 3.7 Connector 1304 - Gyroscope
Pin Description Colour Voltage (DC)
1Brown5.0
2 Not used
3 Not used
4 Not used
Table 3.8 Connector 1305 - Enc 1
Pin Description Colour Voltage (VDC)
1 - GND White 0.0
2 A Yellow
3 B Green
4 + POWER Brown 5.0
