5.4303.8558.0 -
2-8 Safety
• Keep the safety decals clean and legible at all times. Clean the safety decals with soap and water. Do
not use mineral spirits, abrasive cleaners or other similar agents that may damage the safety decals.
• Replace safety decals that are missing or that are illegible.
• Safety decals can be purchased from your local Lely service provider.
2.5 Safety Devices
2.5.1 Emergency Stop Button
An emergency stop button is installed on top of the machine. When the button is pushed, the machine
immediately stops operation. To reset the emergency stop button, pull the button upwards. To resume
operation the alarm must be cleared from the user interface and the pause button must be pushed.
2.5.2 Pause Button
A pause button is installed on the machine. When the pause button is pushed while the machine is in
operation, the machine goes into pause mode:
• The machine stops.
• The LED light in the pause button turns on.
• The operational sound of the machine is turned off.
• The user interface on the smartphone displays the status ‘Paused’.
When the pause button or the button in the app on the smartphone is pushed shortly while the machine is
in pause mode, the machine goes back into work mode:
• The machine goes back into operation.
• The LED light in the pause button turns off.
• The operational sound of the machine is turned on.
When the button in the app on the smartphone is pushed for 5 seconds while the machine is in pause
mode, a popup appears on the screen Are you sure to go out of operation? confirm this and the machine
goes out of operation.
The pause button can be operated remotely with the app on the smartphone, except when an emergency
stop occurred.
If an alarm occurs, the LED in the pause button blinks. The alarm must be confirmed with the app on the
smartphone.
Status of the machine LED status of the pause button
Start up
Blink
Out of operation
On
Paused
On
In operation
Off
Alarms Blink
