4-10 Description and Operation
4.2.10 Charging Station
The charging station is the start and end point for all routes in the day planning. The machine can be left
permanently connected to the charging station. This keeps the battery in good condition. The VCB
continuously examines the voltage of the battery. It is not possible to overcharge the battery.
The charging station has a 20 A electronic battery charger. The battery charger electrodes are at the front
near the bottom of the charging station.
The charging station can be installed in the barn in two ways:
• Wall-mounted.
• Floor-mounted (optional).
If it is not possible to install the charging station to the wall, an optional floor column can be supplied.
Battery charger
The 20 A electronic battery charger has two indicator LEDs on the upper right side. The meaning of the
LEDs are:
Status
Charging
LED (yellow)
Power LED
(green)
Description
Normal operation.
OFF OFF
Power disconnected.
OFF ON
Powered, no battery connected.
ON ON
Powered, battery connected.
Error.
Blinking Blinking
–
in n o vato rs in agriculture
