5.4303.8558.0 -
Safety 2-11
Machine status Shock system status
Out of operation Off
In operation, charging + safety bumper is activated
On
2.5.10 LED Beacon (optional)
The machine is optionally fitted with a LED beacon that makes the machine visible when it drives in the
dark from one barn to another. When the machine is at the charging station the LED beacon is switched
off.
Figure 6. Position of the safety devices
KEY: 1. Bumper with electric pulse (optional) - 2. Pause button - 3. Buzzer (underneath the cover) - 4. LED beacon (optional) - 5.
Emergency stop button
in n o vato rs in agriculture
