5.4303.8558.0 -
Description and Operation 4-29
Display
Description
Wheels
• Driven distance left (km): the total distance the left drive
wheel has travelled in kilometers since the last reset action.
• Driven distance right (km): the total distance the right drive
wheel has travelled in kilometers since the last reset action.
• Driven hours left: the amount of time the left drive wheel has
travelled since the last reset action.
• Driven hours right: the amount of time the right drive wheel
has travelled since the last reset action.
Skirt rubber
• Driven distance: the distance the skirt rubber has travelled
since the last reset action.
Buttons
•
to return to the menu Testing.
•
to enter the menu Manual control.
4.3.3.14 Barn Door
Display
Description
The menu Barn door gives actual information about the barn door.
• Door ID:
• Identification number of the barn door.
• Current state:
• Open: the barn door is currently opened.
• Closed: the barn door is currently closed.
• Manual: the door is set to manual operation.
• Choose action:
• Open.
• Close.
Buttons
•
to return to the menu Testing.
•
to enter the menu Manual control.
