5.4303.8558.0 -
4-8 Description and Operation
The maximum amount of energy the electric pulse of the bumper
transfers is 15mJ (at 500R). This does not harm cows or humans.
The shock system meets the standard EN IEC 60335-2-76 for electric fence
energizers.
The shock system makes sure the cows do not block the machine. Cows are deterred from touching the
machine by an electric pulse on the bumper. The power energizer generates the pulse on the bumper. The
pulse is on when the machine is in operation. When the machine is out of operation the shock system is
off. The power energizer is connected to the VIOB, gets its input from the VCB and sends output to the
bumper.
Figure 13. Shock system
KEY: 1. VIOB - 2. VCB - 3. Power energizer - 4. Bumper with electric pulse
