1. Disengage the PTO.
Wait for all moving parts of the Splendimo to stop.
2.
Pull the operating cord to release the locking hooks on the hydraulic
rams.
3. Operate the tractor hydraulic system to extend the hydraulic ram until
the Splendimo is in the transport position.
4. Make sure the locking hooks have engaged in the hydraulic rams.
Figure 9. Transport Position
Figure 10. Engaged Locking Hook
WARNING
3-4 Operation
M-H021.1004EN
