4.3 Change to Combined or Individual Lifting
Individual lifting of a mower can be used to mow the smaller remainders
of the crop.
1.
Stop the tractor.
2. Disengage the PTO.
Wait for all moving parts of the Splendimo to stop.
Always switch off the tractor engine before you leave the tractor cab.
3. If necessary, set the ball valve on the hydraulic system to the correct
position for either combined or individual lifting and lowering as follows:
• Set the valve to position 1 for individual lifting and lowering.
• Set the valve to position 2 for combined lifting and lowering.
• If the hydraulic system is electrically controlled, set the switch on the
control box to the applicable position.
4. Operate the tractor hydraulic system to lift the Splendimo to the
headland position.
Figure 16. Headland Position Combined Lifting
Figure 17. Headland Position Individual Lifting
Note:
WARNING
WARNING
4-4 Test and Adjustment
M-H021.1004EN
