8. SPECIFICATIONS
8.1 Splendimo 900 M Specifications
Working width 8.85 m
Overlap 2 x 35 cm in combination with Splendimo 320 F
Transport width 2.95 m
Transport height 3.90 m
Number of discs/knives 2 x 8/16
Mowing height ± 30 mm and higher
Infinitely adjustable via the top link
Approximate swath width 2.10 - 2.60 m
Range of operation ± 20º from the horizontal (relative to the tractor)
PTO speed 1000 rpm
Linkage Category III
Hydraulic connections 1 double-acting valve with floating position
1 single-acting valve with floating position
Max. oil pressure 210 bar (21.0 MPa)
Security 1200 Nm 4 plate slip clutch (K92/4)
Power requirement 99 kW (135 hp)
Approximate weight
(excl. front mower)
1940 kg
All specifications may be changed without prior notice.
Note:
Specifications 8-1
M-H021.1004EN
