LELY Splendimo 900 M - Bolt and Nut Torque Table

6.3 Bolt and Nut Torque Table
The following table specifies the standard torque load for all quality 8.8 bolts
in combination with quality 8 nuts on the Splendimo.
Always
use a calibrated torque wrench when you torque-tighten bolts and nuts.
M6 M8 M10 M12 M14 M16 M20 M24
Nm 10 25 50 85 135 215 410 710
kgm 1.0 2.5 5.0 8.5 13.5 21.5 41.0 71.0
6-2 Diagrams and Tables
M-H021.1004EN
