7. TROUBLESHOOTING
The crop flow-trough is irregular.
•
Do not drive too slowly, an effective workspeed starts from 10 km/h.
• Install agitators.
The mower indents the ground.
• Decrease the ground pressure (page 4-2).
The mower floats during operation.
• Increase the ground pressure. (page 4-2)
The crop is mowed at irregular heights.
• Increase the ground pressure (page 4-2).
• Replace the mower knives. (page 5-9)
The crop entangles around the cutter bar and mower discs.
• Maintain a PTO speed as shown on the Splendimo.
A mower element cannot be installed on the drive shaft
• Turn the mower disc several half turns until the element can be installed.
The mowing height of the left and right mower differs.
• Adjust the Oblique Mowing Height (Title Only) (page 4-7).
Troubleshooting 7-1
M-H021.1004EN
