5.2.3 Grease the PTO shaft
• Requirements:
•
Grease pump
• Biodegradable grease (Total Biomultis SEP2 or equivalent)
1. Use the grease pump to grease the PTO shaft.
2. Grease the profiled tubes of the PTO shaft.
Figure 24. Grease Points PTO Shaft
5.2.4 Grease a Mower Element
• Requirements:
•
Shell Alvania WR 0 or equivalent
• Loctite 243
• Torque wrench
Do not use solvent for removing grease from the mower element. Solvent can
cause damage to the seals and bearings.
An incorrect quantity of grease will cause overheating and damage to the
mower element.
Make sure the bearing housing is installed on the same mower element it was
removed from.
1. Remove the split pin (1) from the castellated nut (2) on top of the mower
disc (5).
2. Remove the castellated nut (2).
3. Remove the pressure piece (3).
4. Make sure the O-ring (4) stays inside the pressure piece.
5. Remove the mower disc (5).
CAUTION
CAUTION
CAUTION
5-4 Maintenance
M-H021.1004EN
