6. Adjust the top link of the tractor and the parking jack to align the parts.
Position 1 tilts the mower slightly backwards. Position 2 tilts the mower
slightly forwards.
7.
Install the excentric bush so the left and right mower are parallel and
have the same mowing height.
8. Use a hammer to install the two roll pins in the pivot pin.
9. Remove all tools and equipment from the area.
Figure 22. Adjust the Oblique Mowing Height
Note:
4-8 Test and Adjustment
M-H021.1004EN
